1×4 Singlemode 1U 19″ Rack Mount PLC Splitter
◎ P/N: 122316
◎ Attention: For a formal quote, please send product details to [email protected].
Delivery: Order today and it will be shipped before from the U.S. or Hong Kong via FedEx/DHL/UPS. Free shipping on orders over US$200.
Warranty: Fiber-Life offers a 1-year warranty, 30-day returns, and 30-day exchanges.
$178.40
1×4 Singlemode 1U 19″ Rack Mount PLC Splitter
The 1×4 Singlemode 1U 19″ Rack Mount PLC Splitter is a compact passive optical splitter designed for small to medium-scale signal distribution in FTTx and PON networks. Based on PLC (Planar Lightwave Circuit) technology, it delivers stable splitting performance with low insertion loss and high channel uniformity.
Integrated into a standard 1U 19-inch rack-mount enclosure, this splitter enables centralized fiber management and easy installation in ODFs, central offices, and equipment rooms. It supports singlemode operation across 1260–1650 nm and is fully compatible with GPON, EPON, and 10G PON systems. Custom connector types and pigtail lengths are available to meet diverse deployment needs.
Specifications
| Parameter | 1×2 | 1×4 | 1×8 | 1×16 | 1×32 | 1×64 | 1×128 |
|---|---|---|---|---|---|---|---|
| Operating Wavelength | 1260~1650nm | ||||||
| Fiber Type | G.657.A1 | ||||||
| Insertion Loss | ≤3.8dB | ≤7.2dB | ≤10.3dB | ≤13.5dB | ≤16.5dB | ≤20.5dB | ≤23.8dB |
| Loss Uniformity | ≤0.4dB | ≤0.6dB | ≤0.8dB | ≤1.0dB | ≤1.5dB | ≤2.0dB | ≤2.5dB |
| Polarization Dependent Loss | ≤0.2dB | ≤0.2dB | ≤0.2dB | ≤0.3dB | ≤0.3dB | ≤0.4dB | ≤0.4dB |
| Return Loss | ≥50dB | ||||||
| Directivity | ≥55dB | ||||||
| Wavelength Dependent Loss | ≤0.5dB | ≤0.5dB | ≤0.5dB | ≤0.5dB | ≤1.0dB | ≤1.0dB | ≤1.0dB |
| Temperature Stability | ≤0.5dB | ||||||
| Operating Temperature | -20℃ ~ +85℃ | ||||||
| Storage Temperature | -40℃ ~ +85℃ | ||||||
| Maximum Power Handing | 500mW | ||||||
| Dimension (LxWxH) | 482.6x200x44mm | ||||||
Note: Specified without connectors; add an additional 0.2dB loss per connector.
| Features | Applications |
|---|---|
| Low Insertion Loss | FTTX Systems |
| Low PDL | PON Networks |
| Compact Design | CATV Links |
| Good Channel-to-Channel Uniformity | Optical Signal Distribution |
| High Reliability and Stability |
Dimension Drawing (Unit: mm)
