1310/1550nm 1×2 Filter Type Singlemode Fiber Splitter
◎ P/N: #50206
◎ Attention: For official offers, send product details to sales@fiber-life.com.
Delivery: Order Today, will ship out before from U.S. or HK by FedEx/DHL/UPS (The fastest and best one), and Free Shipping on orders over US $200.
Warranty: fiber-life support 1-Year Warranty, 30-Day Returns and 30-Day Exchange.
$51.00 – $111.00
Singlemode Filter Type Fiber Splitter, 1×2, 1310/1550nm
The 1310/1550nm 1×2 Filter Type Singlemode Fiber Splitter is an advanced optical splitter designed for singlemode fiber systems, supporting both 1310nm and 1550nm wavelengths. It efficiently splits a single input signal into two output ports, making it ideal for long-distance fiber optic communications, WDM (Wavelength Division Multiplexing) systems, and data transmission networks.
The filter-type design minimizes optical loss and interference, ensuring stable and high-quality signal distribution. With low insertion loss and high return loss, it guarantees optimal signal performance. Compatible with standard singlemode fibers, this splitter is perfect for long-haul communications, data centers, and enterprise networks, providing reliable, high-efficiency signal splitting for various network applications.
Specifications
| Parameter | Value |
|---|---|
| Operating Wavelength (nm) | 1310/1550±50 |
| Insertion Loss (dB) (50/50) | ≤3.9/3.9 |
| Insertion Loss (dB) (10/90) | ≤11.3/1.1 |
| Insertion Loss (dB) (5/95) | ≤14.5/0.9 |
| Polarization Dependent Loss (dB) | ≤0.15 |
| Return Loss (dB) | ≥50 |
| Directivity (dB) | ≥50 |
| Maximum Power Handling (mW) | 500 |
| Operating Temperature (°C) | -10~+70 |
| Storage Temperature (°C) | -40~+85 |
| Fiber Type | SMF-28e |
| Package Dimension (mm) (250μm, 900μm) | Ø5.5 × L38 (Steel Tube) |
| Package Dimension (mm) (2.0mm, 3.0mm) | L90 × W20 × H10 (ABS Box) |
