Customized LC/SC/FC/ST In-Line Variable Optic Attenuator (VOA), 0-60dB
◎ P/N: #50490
◎ Attention: For official offers, send product details to sales@fiber-life.com.
Delivery: Order Today, will ship out before from U.S. or HK by FedEx/DHL/UPS (The fastest and best one), and Free Shipping on orders over US $200.
Warranty: fiber-life support 1-Year Warranty, 30-Day Returns and 30-Day Exchange.
- Size Guide
Size Guide
DRESSEST-SHIRTBOTTOMSDRESSESSize Chest Waist Hips XS 34 28 34 S 36 30 36 M 38 32 38 L 40 34 40 XL 42 36 42 2XL 44 38 44 All measurements are in INCHES
and may vary a half inch in either direction.
T-SHIRTSize Chest Waist Hips 2XS 32 26 32 XS 34 28 34 S 36 30 36 M 38 32 38 L 40 34 40 XL 42 36 42 All measurements are in INCHES
and may vary a half inch in either direction.
BOTTOMSSize Chest Waist Hips XS 34 28 34 S 36 30 36 M 38 32 38 L 40 34 40 XL 42 36 42 2XL 44 38 44 All measurements are in INCHES
and may vary a half inch in either direction.
$105.00 – $121.00
Customized LC/SC/FC/ST In-Line Single Mode/Multimode Variable Optic Attenuator (VOA), 0-60dB
An In-Line Variable Optical Attenuator (VOA) is a crucial device in optical communication systems that adjusts the power level of an optical signal. Installed directly in the optical fiber path, it provides precise control over signal attenuation, allowing for variable reduction of signal strength. This adjustment is essential for balancing signal levels, compensating for signal loss, and ensuring optimal performance. The in-line design ensures the VOA integrates seamlessly into the optical network, supporting functions such as signal power leveling, calibration, and testing.
Specifications
Type(nm) | 1310 | 1550 | 1310/1550 | 850/1310 | |||
Wavelength (nm) | 1310±50 | 1550±50 | 1260~1650 | 850±40 Or 1310±40 | |||
Attenuation Range(dB) | 0 ~ 60 | ||||||
Original Loss(dB) | ≤0.8 | ||||||
Return Loss(dB) | ≥50 | ≥30 | |||||
Fiber Type | SMF-28 | 50/125 or 62.5/125 MM | |||||
PDL(dB) | ≤0.15 | ||||||
Operating Temperature (℃) | 0 ~ + 70 | ||||||
Storage Temperature (℃) | 40 ~ + 85 | ||||||
Dimensions (mm) | 26 x 18 x 8 |
Features |
Applications |
High Precise attenuation value | Fiber Optic Communication |
Perfect environmental stability and reliability | DWDM Equipment |
Low insertion loss and additional loss | Fiber Optic CATV |
Flawless end face | Local Area Networks (LAN) |
Wide attenuation range (variable) | |
Precision ceramic ferrule | |
Compact in size | |
Simple and reliable Structure |
Wavelength | 1310nm, 1550nm, 1310/1550nm, 850/1310nm, Custom |
---|---|
Fiber Type | Singlemode 9/125 um, OM1 62.5/125 um, OM2 50/125 um, OM3 50/125 um, OM4 50/125 um |
Fiber Length A | 0.3m, 0.5m, 1m |
Fiber Length B | 0.3m, 0.5m, 1m |
Fiber Diameter | 0.9mm, 2.0mm, 3.0mm |
Connector A | FC/APC, FC/UPC, SC/APC, SC/UPC, LC/APC, LC/UPC, ST/APC, ST/UPC |
Connector B | FC/APC, FC/UPC, SC/APC, SC/UPC, LC/APC, LC/UPC, ST/APC, ST/UPC |
