OM3 Multimode Simplex LC/SC/FC/ST 3.0mm Armored Fiber Optic Patch Cable

◎ P/N: #52634

◎ Attention: For official offers, send product details to sales@fiber-life.com.

Simplex OM3 Multimode Armored Fiber Optic Patch Cable-13Delivery: Order Today, will ship out before from U.S. or HK by FedEx/DHL/UPS (The fastest and best one), and Free Shipping on orders over US $200.

Simplex OM3 Multimode Armored Fiber Optic Patch Cable-14Warranty: fiber-life support 1-Year Warranty, 30-Day Returns and 30-Day Exchange.

  •  Size Guide

    Size Guide

  ... people are viewing this right now

  Share
Guaranteed Safe CheckoutTrust

$3.80$577.00

  Hurry up! Sale end in:

Customized Details

OM3 Multimode Simplex LC/SC/FC/ST 3.0mm Armored Fiber Optic Patch Cable

The OM3 Multimode Simplex LC/SC/FC/ST 3.0mm Armored Fiber Optic Patch Cable is a fiber optic jumper specifically designed for data centers, local area networks (LAN), and high-bandwidth applications. Using OM3 multimode fiber, it supports high-speed data transmission of 10Gbps within short distances of up to 100 meters and can also support 40Gbps and 100Gbps rates under specific conditions.

This simplex cable features a single-fiber structure for simplex data transmission and offers various connector options, including LC, SC, FC, and ST, to accommodate different network devices. With a 3.0mm jacket diameter and armored construction, it provides enhanced resistance to bending and abrasion, making it ideal for high-traffic or harsh environments. This cable is widely used for data center cabling, server room connections, and short-distance, high-bandwidth transmission applications.


Specifications

Connector Type LC/SC/ST/FC Polish Type UPC To UPC
Fiber Mode OM3 50/125μm Wavelength 850/1300nm
Fiber Count Simplex Polarity A (Tx) To B (Rx)
Fiber Grade Bend Insensitive Min. Bend Radius 20/10D (Dynamic/Static)
Cable Jacket PVC/LSZH/OFNP Tensile Load 120/225N (Long/Short Term)
Insertion Loss ≤0.3dB Return Loss ≥30dB
Operating Temperature -25~70°C Storage Temperature -25~70°C

Features

High-pressure Steel Wire Protection

Tubular metal steel wire ring effectively protects the inner fiber core from damage, and can also prevent mechanical damage such as trampling, breakage, and rat bites.
OM3 Multimode Simplex 3.0mm Armored Fiber Optic Patch Cable High-pressure Steel Wire Protection

High-precision Grinding Equipment

Ensures that the center grinding deviation of the optical fiber, the depression of the optical fiber, and the optical fiber surface are free of scratches or defects. The radius of curvature of the ceramic end and other parameters meet the standards.
Armored OS2 SingleMode 6 Fibers 5.0mm Breakout Cable High-precision Grinding Equipment

End Face Detection

End face geometry test to ensure that the end face curvature radius, vertex offset, and fiber height meet the standards.
Armored OS2 SingleMode 6 Fibers 5.0mm Breakout Cable End Face Detection.

Attenuation Detection

Using new materials and high-standard production technology to make the insertion loss change <0.3dB Interchangeability.
Armored OS2 SingleMode 6 Fibers 5.0mm Breakout Cable Attenuation Detection

Three Jacket Materials

The differences between OFNP, PVC, LSZH jackets.

The differences between OFNP, PVC, LSZH jackets.
Fiber Length

1m, 2m, 3m, 5m, 10m, 15m, 20m, 30m, 50m, 100m, 200m, 500m

Connector A

SC/UPC, FC/UPC, LC/UPC, ST/UPC

Connector B

SC/UPC, FC/UPC, LC/UPC, ST/UPC

Cable Jacket

PVC, LSZH, OFNP
