Customized 24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable, Yellow

◎ P/N: #57445

◎ Attention: For official offers, send product details to sales@fiber-life.com.

24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-21Delivery: Order Today, will ship out before from U.S. or HK by FedEx/DHL/UPS (The fastest and best one), and Free Shipping on orders over US $200.

24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-22Warranty: fiber-life support 1-Year Warranty, 30-Day Returns and 30-Day Exchange.

  •  Size Guide

    Size Guide

  ... people are viewing this right now

  Share
Guaranteed Safe CheckoutTrust

$154.77$2,474.92

  Hurry up! Sale end in:

Customized Details

24-144 Fibers OS2 Single Mode MTP Breakout Cable

MTP breakout cable, a cost-effective alternative to time-consuming field termination, is designed for high-density fiber patching in data centers which need space saving and reduce cable management troubles.

Please note: The US Conec MTP® connectors are fully compliant with the MPO standards, achieving higher performance levels when compared to generic MPO connectors.


Specifications

Connector A US Conec MTP® Connector B LC/SC/FC/ST
Fiber Mode OS2 9/125μm Wavelength 1310/1550nm
Glass Fiber Corning SMF-28® Ultra Minimum Bend Radius 10mm
Trunk Diameter 3.0mm-11.7mm Breakout Leg 2.0mm (Duplex), 2.0/0.9mm (Simplex)
MTP Connector IL ≤0.35dB Standard Connectors IL UPC≤0.2dB, APC≤0.3dB
MTP Connector RL ≥60dB Standard Connectors RL UPC≥50dB, APC≥60dB

*MTP is a registered trademark of US Conec Ltd. US Conec and Fiber-Life partner on supplying high performance MTP series products.

Note:
1.The default diameter of the MTP cable is 3.0mm.
2.The diameter of branch cable is 2.0mm,please kindly contact us at sales@fiber-life.com for other diameter standard.


Quality Certifications

24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-124-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-224-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-424-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-424-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-524-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-6

Features

Custom Fiber Count
24-144F cables are the combination of MTP®-24 cable assemblies.
                                          24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-7              24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-8
                                         24F mainly used for 100G CXP/CFP/CPAK optics direct connection.          8-144F mainly used for 10G/40G/100G high-density structural fiber cabling.

Custom Cable Jacket

The OFNP cables have the highest fire rating for vertical runs between floors in data centers. The LSZH cables make little smoke and no halogen for horizontal structural cabling areas.

24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-9

Custom Connectors

            24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-1024-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-11



  1. The female (without pins) connector can be directly connected to transceivers or other male connectors.
  2. The male (with pins) connector is mated to the female side for adapters, cassettes or panels connection.

Custom Standard Connectors

                                             24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-12                                          24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-13
                     Mainly used for matching SFP/SFP+/XFP transceivers and LC adapters.            Mainly used for matching GBIC/X2/XENPAK transceivers and SC adapters.
                                            24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-14                                               24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-15
                      Mainly used for datacom, FTTH, campuses, corporate networks etc.                         Mainly used for datacom, measurement equipment, lasers etc.

Custom Pulling Eye

                                 24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-16                                           24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-17
                                                     Without pulling eye is suited for                                                                                     With pulling eye could protect cables
                                                short cables in common fiber cabling.                                                                            when pulling through long distance conduit.

Custom Polarity

Master fiber polarity knowledge to manage and optimize your network and connection. You can also click the Technical White Paper if you have any interest or questions about polarity.

24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-18

MTP&MPO Difference

The term MTP is a registered trademark of US Conec, it has been the main trend in European and American areas.

                        24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-19 24-144 Fibers MTP®-24 OS2 Single Mode Elite MTP Breakout Cable-20
Fiber Count

24 Fibers(1×24), 48 Fibers(2×24), 72 Fibers(3×24), 96 Fibers(4×24), 144 Fibers(6×24)

Fiber Length

1m, 3m, 5m, 10m, 15m, 20m, 30m, 50m, 100m

Connector A

Female APC 0.35dB, Male APC 0.35dB

Connector B

SC/UPC Simplex, SC/UPC Duplex, FC/UPC Simplex, LC/UPC Simplex, LC/UPC Duplex, ST/UPC Simplex, SC/APC Simplex, SC/APC Duplex, FC/APC Simplex, LC/APC Simplex, LC/APC Duplex, ST/APC Simplex

Cable Jacket

OFNP, LSZH

Polarity

Type C Cross Pair, Type B Cross, Type A Straight Through

Breakout Length

0.3m, 0.5m

Pulling Eye

End A, End B, Both Ends, None
