Customized FC to FC Simplex Single Mode/Multimode Metal Small D Fiber Optic Adapter/Coupler without Flange
◎ P/N: #62565
◎ Attention: For official offers, send product details to sales@fiber-life.com.
Delivery: Order Today, will ship out before 4/1/2025 from U.S. or HK by FedEx/DHL/UPS (The fastest and best one), and Free Shipping on orders over US $200.
Warranty: fiber-life support 1-Year Warranty, 30-Day Returns and 30-Day Exchange.
$1.30 – $8.30
FC to FC Singlemode/Multimode Simplex Small D Fiber Adapter, Female to Female, 0.2dB/0.1dB Insertion Loss
Fiber optic adapters, also known as couplers, are compact devices engineered to terminate or connect fiber optic cables and connectors across two fiber optic lines. These adapters facilitate the precise alignment of two connectors, ensuring that light signals are transmitted with minimal loss and maximum efficiency.
Fiber optic adapters are prized for their low insertion loss, which is crucial for maintaining signal integrity over long distances. They also offer excellent interchangeability and reproducibility, ensuring consistent performance regardless of the connectors being used.
FiberLife offers an extensive selection of mating sleeves and hybrid adapters, catering to a variety of applications. Among our offerings are specialized male-to-female hybrid fiber optic adapters, designed to meet unique requirements in fiber optic networking.
Specifications
| Connector Type | FC-FC | Body Style | Simplex |
| Polish Type | UPC/APC | Fiber Mode | Singlemode/Multimode |
| Insertion Loss | ≤0.2dB/<0.1dB | Durability | 1000 Times |
| Mounting Type | Reduced Flanged | Alignment Sleeve Material | Ceramic |
| Working Temperature | -25 To 70°C (-13 To 158℉） | Flammability Rate | UL 94V-0 |
Quality Certifications
.svg)
Features
Extending Fiber Connection with Adapters
The adapters, featuring high-precision components and a tool-less design, enable seamless, long-distance communication between devices via direct fiber optic connections.
Protective Dust Cap Refined Ceramic Sleeve One-piece Design
Prevent the adapter from dust and keep it clean. Ensure the maximum connection between fiber jumpers. Make the adapter no risk of separation and rupture.
Nickel-plated Copper Protects the Metal from Corrosion
The adapter is made of machining, its structure is more sturdy with high hardness and precision.
Grace Henry –
I purchased this FC/APC to FC/APC single-mode simplex small D-type adapter, which offers low insertion loss.
Emre Yılmaz –
Fast delivery, good service, will buy again.
