460nm~680nm Visible Wavelength Polarization Maintaining (PM) Singlemode Simplex Fiber Patch Cable Slow/Fast Axis Working
◎ P/N: #72629
◎ Attention: For official offers, send product details to sales@fiber-life.com.
Delivery: Order Today, will ship out before from U.S. or HK by FedEx/DHL/UPS (The fastest and best one), and Free Shipping on orders over US $200.
Warranty: fiber-life support 1-Year Warranty, 30-Day Returns and 30-Day Exchange.
$135.00 – $1,287.00
Polarization Maintaining PM Simplex SMF Fiber Patch Cable 460nm~680nm Visible Wavelength Slow/Fast Axis Working PM Patch Cord
FiberLife visible wavelength polarization-maintaining fiber patch cable covers multiple visible light wavelengths such as 460nm, 488nm, 532nm, 588nm, 632nm, 638nm, 650nm, 680nm. Polarization-maintaining fiber patch cable is a specialized fiber optic cable designed to preserve the polarization state of light signals. FiberLife high-quality pm fiber patch cord uses imported connectors to reduce loss and improve extinction ratio and return loss.
Specification
| Indicator Name | Limit Value | Standard Value | Unit |
| Central Wavelength | 460, 488, 532, 590, 632, 638, 650, 680 Or Customize | nm | |
| Connector Type | FC, SC, LC, ST, MU, D4 | ||
| Insertion Loss (Typical) | 0.90 | dB | |
| Insertion Loss | Max. | 1.5 | dB |
| Extinction Ratio | Min. | 20 | dB |
| Return Loss | Min. | 45 For UPC, 50 For APC | dB |
| Interactivity | Max. | 0.5 | dB |
| Repeatability | Max. | max. 0.5dB For 1000 Mating | dB |
| Fiber Type | Nufern PM460 HP Or Nufern PM630 HP | ||
| Power handling (CW) | Max. | 50 | mW |
| Tensile Oad | Max. | 5 | N |
| Operating Temperature | -20 To +85 | ℃ | |
| Storage Temperature | -40 To +85 | ℃ |
Fiber Optic Polarization Coordinate System
An explicit coordinate system must be specified in order to unambiguously describe a state of polarization. This is shown in the following illustration.
| Wavelength | 460nm, 488nm, 532nm, 590nm, 632nm, 638nm, 650nm, 680nm, Customize |
|---|---|
| Fiber Type | Nufern PM460 HP, Nufern PM630 HP |
| Fiber Length | 1m, 2m, 3m, 5m, 10m, 15m, 20m, 30m |
| Fiber Diameter | 250um, 900um, 2.0mm, 3.0mm |
| Connector A | SC/APC, SC/UPC, FC/APC, FC/UPC, LC/APC, LC/UPC, ST/APC, ST/UPC |
| Connector B | SC/APC, SC/UPC, FC/APC, FC/UPC, LC/APC, LC/UPC, ST/APC, ST/UPC |
| Cable Jacket | PVC, LSZH |
| Working Axis | Slow Axis, Fast Axis |
