1xN, 2xN Dual Window FBT Splitter With Steel Tube
◎ P/N: #76097
◎ Attention: For official offers, send product details to sales@fiber-life.com.
Delivery: Order Today, will ship out before from U.S. or HK by FedEx/DHL/UPS (The fastest and best one), and Free Shipping on orders over US $200.
Warranty: fiber-life support 1-Year Warranty, 30-Day Returns and 30-Day Exchange.
$12.50 – $99.30
1xN, 2xN Dual Window FBT Splitter With Steel Tube
The 1xN, 2xN Dual Window FBT Splitter with Steel Tube is a fiber optic splitter that uses Fused Biconical Taper (FBT) technology to divide an optical signal from one or two input fibers into multiple outputs. It supports 1310 nm and 1550 nm wavelengths, making it suitable for both short and long-range transmissions. The steel tube casing provides protection against environmental damage, ensuring durability and reliability in outdoor and industrial environments. This splitter is commonly used in telecommunications, FTTH, and data centers for efficient signal distribution.
Specification
| Parameter | Unit | Dual Window FBT Splitter |
|---|---|---|
| Operating Wavelength | nm | 1310/1550 |
| Operating Bandwidth | nm | ±40 |
| Typical Excess Loss | dB | ≤0.07 |
| Insertion Loss (50/50) | dB | ≤3.6 |
| Insertion Loss (40/60) | dB | ≤4.7/2.7 |
| Insertion Loss (33/67) | dB | ≤5.7/2.2 |
| Insertion Loss (30/70) | dB | ≤6.0/1.9 |
| Insertion Loss (20/80 ) | dB | ≤7.9/1.3 |
| Insertion Loss (10/90) | dB | ≤11.2/0.75 |
| Insertion Loss (5/95) | dB | ≤14.15/0.4 |
| Insertion Loss (3/97) | dB | ≤16.45/0.3 |
| Insertion Loss (2/98) | dB | ≤18.45/0.3 |
| Insertion Loss (1/99) | dB | ≤21.6/0.25 |
| PDL | dB | ≤0.15 |
| Directivity | dB | ≥55 |
| Return Loss | dB | ≥50 |
| Operating Temperature | ℃ | -10 ~ +70 |
| Storage Temperature | ℃ | -40 ~ +85 |
| Dimension | mm | Φ3×54 |
Note: Above specification is for devices without connector. Add an additional 0.2dB loss per connector.
Dimension
| Port Configuration | 1×2, 1×3, 1×4, 1×6, 1×8, 2×2 |
|---|---|
| Wavelength | 1310/1550nm(Default), 1310/1490nm, 1490/1550nm |
| Fiber Diameter | 250μm, 0.9mm |
| Fiber Length | 1.0m, 1.5m, 2.0m |
| Connector | SC/APC, SC/UPC, FC/APC, FC/UPC, LC/APC, LC/UPC, ST/APC, ST/UPC, None |
| Split Ratios | 1/99, 2/98, 3/97, 5/95, 10/90, 20/80, 30/70, 40/60, 50/50, Customize |
