Customized 1xN, 2xN PM PLC Splitter ABS Box Slow/Fast Axis Working Polarization Maintaining Fiber Splitter
◎ P/N: #49897
◎ Attention: For official offers, send product details to sales@fiber-life.com.
Delivery: Order Today, will ship out before from U.S. or HK by FedEx/DHL/UPS (The fastest and best one), and Free Shipping on orders over US $200.
Warranty: fiber-life support 1-Year Warranty, 30-Day Returns and 30-Day Exchange.
$201.00 – $4,800.00
1xN,2xN PM PLC Splitter, PM Fiber Splitter, Fiber Polarization Maintaining PLC Splitter Slow/Fast Axis Working Plastic ABS Box Package
A PM PLC Splitter (Polarization Maintaining Planar Lightwave Circuit Splitter) is an advanced optical splitter that uses planar lightwave circuit technology to divide optical signals while preserving their polarization state. This feature is crucial for applications that require the polarization of light to be maintained, such as coherent optical communication, high-speed data transmission, and optical fiber sensing. The PM PLC Splitter ensures precise, low-loss signal splitting with consistent performance, making it ideal for high-performance communication systems where polarization integrity is essential.
Specification
| Parameters | 1×2 | 1×3 | 1×4 | 1×6 | 1×8 | 1×12 | 1×16 | 1×24 | 1×32 | 1×64 |
| Operating Wavelength（nm） | 1310 or 1550 or Specify | |||||||||
| Insertion Loss (@23℃)(dB) | ≤3.8 | ≤6.2 | ≤7 | ≤9.4 | ≤10.2 | ≤12.6 | ≤13.5 | ≤15.8 | ≤16.6 | ≤21 |
| Consistency（dB） | ≤0.3 | ≤0.5 | ≤0.4 | ≤0.6 | ≤0.4 | ≤0.8 | ≤0.6 | ≤1.1 | ≤0.8 | ≤1.5 |
| Extinction Ratio (@23℃)(dB) | ≥23 | ≥23 | ≥23 | ≥22 | ≥22 | ≥22 | ≥20 | ≥20 | ≥18 | ≥18 |
| Return Loss(dB) | ≥50 | |||||||||
| Power Handling (mW) | 500 or Specify | |||||||||
| Fiber Type | PM1310 or PM1550 or Specify | |||||||||
| Connector | LC, FC, SC | |||||||||
| Working axis | Slow Axis、Fast Axis or Specify | |||||||||
| Fiber Length tolerance（%） | ±10 or Specify | |||||||||
| Operating Temperature(℃) | -5~70 | |||||||||
| Storage Temperature(℃) | -45~85 | |||||||||
Note:
For device with connector, IL is 0.3dB higher, RL is 5dB lower, ER is 2dB lower.
Specifications may change without notice.
Features |
Applications |
| Low Insertion loss | FTTH, PON, CATV |
| High Return Loss | EDFA & Raman Amplifier |
| High Extinction Ratio | Fiber Sensor |
| Good channel-to-channel uniformity | Fiber Optical Instrument |
| Wide Operating Temperature:From -20℃ to 75℃ | |
| High Reliability and Stability |
Mechanical Drawing(mm)
2×16 PM PLC Fiber Splitter For Reference
| Models | 1×2, 1×3, 1×4, 1×6, 1×8, 1×12, 1×16, 1×24, 1×32, 1×64, 2×2 |
|---|---|
| Working Axis | Slow Axis, Fast Axis, Both Axis |
| Wavelength | 1550nm, 1310nm, Custom |
| Fiber Diameter | 0.9mm, 2.0mm, 3.0mm |
| Fiber Length | 1.0m, 1.5m, 2.0m |
| Connectors | SC/APC, SC/UPC, FC/APC, FC/UPC, LC/APC, LC/UPC, ST/APC, ST/UPC, None |
