1xN, 2xN 850nm/1310nm Single Window Multimode FBT Splitter With Steel Tube
◎ P/N: #77006
◎ Attention: For official offers, send product details to sales@fiber-life.com.
Delivery: Order Today, will ship out before from U.S. or HK by FedEx/DHL/UPS (The fastest and best one), and Free Shipping on orders over US $200.
Warranty: fiber-life support 1-Year Warranty, 30-Day Returns and 30-Day Exchange.
$23.75 – $100.00
1xN, 2xN 850nm/1310nm Single Window Multimode FBT Splitter With Steel Tube
The 1xN, 2xN 850nm/1310nm Single Window Multimode FBT Splitter with Steel Tube is an optical splitter designed for multimode fiber networks, available in 1xN or 2xN configurations. It splits one or two input fibers into multiple output fibers, with support for 850nm or 1310nm wavelengths, commonly used for short to medium-distance transmissions.
Utilizing the FBT (Fused Biconical Taper) technique, it provides a reliable and cost-effective way to distribute signals. The steel tube ensures mechanical protection, making the splitter durable and ideal for telecom and data center applications, where performance and reliability are crucial.
Specifications
| Parameter | Unit | Single Window FBT Splitter(Multimode) |
|---|---|---|
| Operating Wavelength | nm | 850 or 1310 |
| Operating Bandwidth | nm | ±40 |
| Typical Excess Loss | dB | ≤0.4 |
| Insertion Loss (50/50) | dB | ≤3.7 |
| Insertion Loss (40/60) | dB | ≤4.2/2.7 |
| Insertion Loss (33/67) | dB | ≤5.7/2.2 |
| Insertion Loss (30/70) | dB | ≤6.0/2.1 |
| Insertion Loss (20/80 ) | dB | ≤7.8/1.4 |
| Insertion Loss (10/90) | dB | ≤11.2/0.9 |
| Insertion Loss (5/95) | dB | ≤14.5/0.7 |
| Insertion Loss (3/97) | dB | ≤16.15/0.3 |
| Insertion Loss (2/98) | dB | ≤18.6/0.6 |
| Insertion Loss (1/99) | dB | ≤22/0.5 |
| PDL | dB | / |
| Directivity | dB | ≥40 |
| Return Loss | dB | ≥30 |
| Operating Temperature | ℃ | -10 ~ +70 |
| Storage Temperature | ℃ | -40 ~ +85 |
| Dimension | mm | Φ3×54 |
Note: Above specification is for devices without connector. Add an additional 0.2dB loss per connector.
Dimension
